Tsunesaburo kanna restoration: 2. The blade/iron and chipbreaker

This post details restoration of a kanna by Tsunesaburo and continues from Part 1.
I correct the ‘ears’ on the blade with a white wheel on a stationary bench grinder. I make sure to mark the width I need to go to on each side first; then, at the machine, I just take it slow and use water as a coolant. I should also add I freehand this. Using some form of a jig, or at least a tool rest, will no doubt allow more consistent and repeatable results than mine. Even with my crude, simple technique the blade soon starts looking much better.
Bearded Witch Tsunesaburo-10

Most importantly, the edge is now centred. I grind a bit more than I need since I will be removing the chips in the edge and increasing the bevel angle, therefore shortening the blade. This will widen the edge again. I may need to fine tune it later. This is an ongoing maintenance aspect anyway and is very quick to do.

While at the grinder, I also take off the mushroomed sections at the top of the iron and the chipbreaker. This is a bit awkward to do since visibility is greatly reduced at the angle you need to hold the blade at (unless you want to introduce a bevel).  If you fancy giving one of your kannas a similar treatment but feel a bit apprehensive, you can just forego the grinder and use a file. The top half of your kanna will be made of either soft steel or iron, and will be very easy to work by hand.

BBW Tsunesaburo Part 2-2

Straight off the grinder

After grinding, I finesse the surface slightly with a second cut metal file. My intention is to rust blue the exposed bare metal later in order to somewhat blend these areas in.

BBW Tsunesaburo Part 2-3

After filing

I now turn my attention to the edge itself, and that shallow bevel angle. Continue reading →

Tsunesaburo kanna restoration: 1. The Look-see.

A lot has happened since I last wrote something here as I tend to use Instagram for short stories from the workshop these days. I had to impale my thumb on a sharp blade to actually take the time out and write something for this blog. I hope to do that more often (writing, not impaling!).

Tsunesaburo Kage

I mentioned this kanna on Instagram before; it was made by 3rd generation Tsunesaburo in Super Blue Paper steel. Since it arrived from Japan almost two months ago, the wooden body has had more than enough time to acclimate. Now I finally had a moment to sit down, have a look at the kanna in detail and see what is required to bring this secondhand tool back into service. So, before I do anything, let’s take stock of what we are dealing with here…

The dai

The dai is very well made in proper Japanese red oak (this is the true hon akagashi!), and generally well fitted, with one unorthodox treatment. There is a series of overlapping relief cuts clearly made with a gouge, in the lower part of the plane bed.

Bearded Witch Tsunesaburo-1

An unusually relieved section like that would have probably provided a quick way to ease an aspect of tightness in fit, or perhaps to eliminate Continue reading →

Silver Inlay Box

The black walnut box with silver inlay and sycamore as secondary wood is now complete and as always was made entirely with hand tools only.

This project draws inspiration from Japanese art and architecture and the first concept drawing echoed the architectural feel of a torii (鳥居) gate lintel. This was further refined as the small project developed.

The exposed dovetail joinery follows the curves of the ends of the box for an organic feel.

Silver Inlay Box-1

Ornamentation in sterling silver is a simple, nature-inspired illustration in the lid, with the elements in the front of the box tying the composition visually and providing grounding to the shapes of the grasses in the lid. Continue reading →

Humility and Giving

The first thing I ever carved was this love spoon in mahogany that I made for a friends’ wedding, with a presentation box in oak and sapele based on the Mastermyr chest. Not the finest love spoon in the world by a very considerable margin, and certainly not the finest example of box making, but this was an important piece from a personal perspective. Please read on as I’d like to tell you why.

Love spoon and box-8

Viking Chest for a Child: chest build and completion

Having carved the lid, we are looking at the rest of the Viking chest today. The form of the box I am making is based on the Mastermyr chest, which is a Viking-made tool chest found in the 1930s in Gotland, Sweden. A farmer, while ploughing for the first time an area reclaimed after draining a lake and a mire, hit on and pulled from the ground an iron chain. The other end of the chain was tangled around an oak box full of woodworking and metalworking tools from the Viking age.

img_2279

A drawing of the original box. A bit worse for wear and tear but who can complain, after 1,000 years?

The bog environment preserved the box and its contexts in a remarkably good condition for their age (1,000 years). The chest and some 200 tools and blacksmith-made items, including a few fascinating locks, are held in the Swedish History Museum in Stockholm.

viking-chest-for-a-child-5

My version of the Mastermyr chest, reinterpreted as a box for a child. I do not get any buzz from creating exact replicas, and treat any source material as inspiration.

I like the form and the joinery involved. Because the ends and sides are angled in (not square), it’s more fun than a regular box. And because of the joinery, when you glue it up, you have to do it all in one go. It’s a bit like a puzzle piece to assemble.

Continue reading →

Legacy, skill, creativity…

We are almost into the New Year and this is traditionally the time when people try and sum up the year behind, and look with expectation to the year ahead. This has been a year of great change and challenge for me. To take stock I looked back, beyond just the last 12 months, and looked around me today so that I can plan into the future. This one is much bigger than just woodworking.
legacy-7

Concept sketches and lettering attempts for what would become a parting present for a colleague and friend.

I think of my family and ask myself, what have I invested here? Will it pay off? Difficult questions to answer, and all too easy to feel inadequate as a parent. Too many hopes and wishes, and not enough tangible stuff. We invest time, effort, love and care and it usually does pay off, but how will your kids remember you? What part of who you are will still live on when you’re not around anymore? If I am not here tomorrow, what would my legacy be?
legacy-6

The resulting carving that grew from the preliminary drawings above, and from the direction my gouges and hands took those first ideas in. This has been the year I decided carving was not beyond me and as always I found I have so much to learn…

Continue reading →

VIKING CHEST FOR A CHILD: CARVING THE LID (PART 2)

I’m back to the carving on the lid of the Viking chest. After wasting away most of the ‘negative space’ material from the background, time to do some further shaping and to put some detail in.



img_0570

Suckers. This is small scale repetitive work and I wasn’t sure what I wanted to do here, really, so I tried a couple of approaches on a section. I forgot I wanted some suckers on a section where they face directly up and I hadn’t left enough wood for them. Worked around that ok, not ideal. At least by the time I got to do further arms I worked out a sequence to simplify this part of the work.



img_0573

The main thing I try and accomplish is something with good balance and proportions that doesn’t look mechanical.

Continue reading →

Viking chest for a child: carving the lid (Part 1)

I started carving the lid for a wee chest I have made. I made the chest in oak but, although I punish myself regularly, the carving will get done in black walnut, a very agreeable species to carve. I had a few unusually clear boards to chose from which helped as well.

img_0248

First, the underside gets a lightly scalloped and textured surface with the edges left intact.



img_0245

On the top, spray adhesive gets a photocopy of the carving design stuck onto the surface so that I can carve through the paper. You can’t see the grain this way but it’s quicker than drawing it all again. I just letter in the recipient’s name.

Continue reading →

Bucket lists and Japanese saws

img_0045

This blade was made by Mitsukawa in Japan and bar fully hand-forged saws it is one of the best of its kind. Mitsukawa make beautiful handles for their saws but I can work with my simple solution no bother.

Inspired by a friend, I started working on a list of things to do in the coming days and weeks. Things I have wanted or thought of doing but had other stuff get in the way. It was inevitable that some of these things would get me into the workshop and I started with a simple one: making an unused or unusable tool into a functional one. I have restored old tools before but was looking for something else.

Continue reading →
